Features

• Dual Open-Drain Buffer Configuration
• -24-mA Output Drive at 3.3 V
• Support Translation-Up and Down
• Available in the Texas Instruments NanoFree™ Package
• Supports 5-V VCC Operation
• Inputs and Open-Drain Outputs Accept Voltages Up to 5.5 V
• Max tpd of 3.7 ns at 3.3 V
• Low Power Consumption, 10-μA Max ICC
• Typical VOLP (Output Ground Bounce) <0.8 V at VCC = 3.3 V, TA = 25°C
• Typical VOHV (Output VOH Undershoot) >2 V at VCC = 3.3 V, TA = 25°C
• Ioff Supports Live Insertion, Partial-Power-Down Mode, and Back-Drive Protection
• Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II
• ESD Protection Exceeds JESD 22 – 2000-V Human-Body Model (A114-A) – 200-V Machine Model (A115-A) – 1000-V Charged-Device Model (C101)
