SJK-6K3-32.768-12.5-20-70-C
Manufacturer's P/N: SJK-6K3-32.768-12.5-20-70-C
Manufacturer: SHENZHEN CRYSTAL TECHNOLOGY INDUSTRIAL CO., LTD.

Crystal unit SJK-6K3-32.768-12.5-20-70-C 32.768kHz 12.5pF 20ppm 3.2x1.5mm
Frequency32,7680kHz
Sort of the elementquartz crystal
Standard packaging:
1000 pcs.
Minimum order:
1 pcs.
Minimum batch:
1000 pcs.
In stock:
Available

Specification:

  • frequency: 32.768KHz
  • frequency tolerance (at 25°C): ±20ppm
  • load capacitance(CL): 12.5pF
  • ESR: 70KΩ max
  • turnover temperature: 25 ± 5°C
  • frequency temperature curve: -0.04ppm/°C² MAX
  • storage temperature range: -55 °C to +125 °C
  • operating temperature range: -40 °C to +85 °C
  • shunt capacitance (C0): 1.2pF typ
  • dynamic capacitance (C1): 3.7fF typ
  • driver level (typical): 0.5 µW max
  • insulation resistance: 500MΩ MIN at DC100V±15V
  • aging @25°C 1st year (max): ±3ppm/year max
