EM320-TH-MAGNET-868M

Manufacturer's P/N: EM320-TH-MAGNET-868M

Manufacturer: XIAMEN MILESIGHT IOT CO. , LTD.

LoRaWAN Temperature and Humidity Sensor (Magnetic Adsorption)

Rodzaj Pomiaru	sensor - temp, wilg.
Do użytku	zewnętrznego
Zastosowanie	mierniki temp. i wilg.
Zasilanie	bateryjne
Operating temperature range [°C]	-30°C +60°C

Standard packaging:

1 pcs.

Minimum order:

1 pcs.

In stock:

Available

Features:

Specification:

wireless transmission
- technology: LoRaWAN®
- frequency: CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4
- Tx power: 16dBm (868)/20dBm(915)/19dBm(470)
- sensitivity: -137dBm @300bps
- mode: OTAA/ABP Class A
measurement
- temperature
  - range: -30°C to + 60°C
  - accuracy: +/- 0.2°C
  - resolution: 0.1°C
- humidity:
  - range: 0% to 100% RH
  - accuracy: +/- 2%
  - resolution: 0.5% RH
operation
- power on & off: NFC configuration via mobile app, power button (internal)
- configuration: NFC Configuration via mobile app
physical characteristics
power supply: 2 × 2700 mAh ER14505 Li-SOCL2 Batteries
- battery life*: ≥5 years (10 min interval with data retransmission disabled)
- operating temperature: -30°C to +60°C
- relative humidity: ≤95%
- material: PC + ABS (Food-Grade)
- color: white
- ingress protection: IP67
- dimension: 85 × 58 × 18 mm (3.34 × 2.28 × 0.70 in)
- installation:
  - magnet version: magnetic adsorption
