AMEL10-5SMJZ
Manufacturer's P/N: AMEL10-5SMJZ
Manufacturer: Aimtec Inc.
Show more information about the brand Aimtec Inc.

AIMTEC AC-DC converter 10W 85-264VAC +5V Uisol=4kVAC
TypeAC/DC
Output power10W
Input voltage85-264VAC
Output voltages5V
AssemblyTHT
ChassisDIP
Standard packaging:
35 pcs.
Minimum order:
35 pcs.
Minimum batch:
35 pcs.
In stock:
Ask

Features:

  • I/O Isolation 4000VAC
  • Low no load consumption ≤0.5W
  • Operating Temp: -25°C to +70°C
  • Continuous Short Circuit Protection
  • Over current, Over Voltage
  • Up to 83% efficiency
  • Input: 85-264VAC, 47-440Hz, or 100-370VDC

Specification:

  • input voltage: 85-264 VAC / 47-440 Hz / 100-370 VDC
  • max output wattage: 10 W
  • output voltage: 5 V
  • output current max: 2A
  • isolation: 4000 VDC
  • maximum capacitive load: 12,000uF
  • efficiency: 76%
