modular voltage converters

AM2GH-4805SZ
Manufacturer's P/N: AM2GH-4805SZ
Manufacturer: Aimtec Inc.
Show more information about the brand Aimtec Inc.

AIMTEC DC-DC converter 2W +48V/+5V Uisol=1.6kV 2:1
TypeDC/DC
Output power2W
Input voltage48V
Output voltages5V
ChassisSIP8
Standard packaging:
1 pcs.

Minimum order:
1 pcs.

Minimum batch:
1 pcs.

In stock:
Ask

Features:

  • operating temperature -40oC to + 85oC
  • ultra-wide input range 4:1
  • continuous short circuit protection
  • low ripple and noise
  • SIP8 package
  • remote on/off control

Specification:

  • input voltage: 18-75V
  • output voltage: 5V
  • output current max: 400mA
  • isolation: 1600VDC
  • input current full load: 55mA
  • input current no load: 15mA
  • efficiency: 75%
