7A-25.000MAAJ-T
Manufacturer's P/N: 7A-25.000MAAJ-T
Manufacturer: TXC CORPORATION

SMD Glass Sealing Crystals 5.0 x 3.2 x 1.2 mm 7A Series +/- 30 ppm, 18pF, 50 R,
Frequency25,0000MHz
Sort of the elementquartz crystal
Chassis5,0mm*3,2mm
Operating temperature range [°C]-20 °C +70 °C
Standard packaging:
1000 pcs.
Minimum order:
1000 pcs.
Minimum batch:
1000 pcs.
In stock:
Ask

Features:

  • 2 pads SMD glass sealed crystal units.
  • High reliable environmental performance.
  • Tight tolerance and stability parts are available.
  • Designed for automatic mounting and reflow soldering.
  • Reasonable cost and good delivery performance.
  • The best choice of portable PC, PDA, DSC, and USB interface card.
  • Contains Pb in sealing glass exempted by RoHS directive
  • Frequency Range: 8 ~ 54 MHz
  • Operating Temperature Range: -10 ~ +70 ℃
