74HC595D/FAITR
Manufacturer's P/N: MM74HC595MX
Manufacturer: ON Semiconductor

8-bit 3-State Shift Register/Latch
Programmable (Y/N)?no
SeriesHC
Logical functionShift Register
Number of items1
ChassisSOIC
Standard packaging:
5 pcs.
Minimum order:
10 pcs.
Minimum batch:
5 pcs.
In stock:
Available

Features:

  • Technology Family HC
  • VCC (Min) 2 (V)
  • VCC (Max) 6 (V)
  • Voltage (Nom) 6 (V)
  • F @ nom voltage (Max) 28 (MHz)
  • ICC @ nom voltage (Max) 0.08 (mA)
  • tpd @ nom Voltage (Max) 41 (ns)
  • IOL (Max) 7.8 (mA)
  • IOH (Max) -7.8 (mA)
  • 3-state output Yes
  • Rating Catalog
  • Operating temperature range -55oC to 125oC)
